Extruded
side facing
away from
gasket
Latch Installation
Preassemble latch, screws and gasket
Correct position
of wire
Incorrect position
of wire
IMPORTANT: Drill bit diameter to not exceed .161 in (4.1 mm). Do not drill into the short sides of the enclosure.
Note: Drill 1/16" pilot hole first, then drill 5/32" or 4mm
hole for two latches and two hinges.
Note: Drill 1/16" pilot hole first, then drill 5/32" or 4mm
hole for four latches and four hinges in locations as
circled in diagram.
Drill Holes in Base 1
2
2
2 1
1
3
4
1
6 - 12 lb-in
2
9 in.
9 in.
2-1/2 in.
2-1/2 in.
22" Long Enclosures
(598-BS22115_, -BS22157_)
7-1/2" thru 15" Long Enclosures
(598-BS885_ -BS1187_, -BS1587_, -BS11115_,
-BS13115_, -BS15117_)
2-1/2 in.
2-1/2 in.
9 in.
9 in.
Hinge Side Latch Side
IMPORTANT: Each latch assembly must have one gasket installed on each side of enclosure wall.
(2)
Hinge Side
Latch Side
2 4
