Rockwell Automation 20P PowerFlex DC Drive - Frame B Field Circuit Board User Manual
Page 10
10
PowerFlex® DC Drive - Frame B Field Circuit Board
10. Remove the cables from connectors X3, X4 and XP on the Pulse
Transformer board (see
11. Remove the ground connection at the left side of the Pulse Transformer
board.
Remove cable
Remove cable
Remove cable
Remove ground
connection
