NOTE: New settings to HIM parameters are implemented immediately.
Resetting the HIM is not required for new values to take effect.
12
[Ref Scaling]
Enables or disables scaling the Reference to a user-defined value.
When Parameter 12 - [Ref Scaling] is set to “1” (Enabled), use HIM
Parameters 13…22 to scale the Reference.
Default:
0 = Disabled
Values:
0 = Disabled
1 = Enabled
Type:
Read/Write
13
[Ref Max Value]
Sets the user-defined value to be displayed when the drive is running
at 60 Hz.
Default:
600
Minimum: 100
Maximum: 65535
Type:
Read/Write
14
[Ref Dec Position]
Sets the number of digits to be displayed to the right of the decimal
point for the Reference.
Default:
1
Minimum: 0
Maximum: 3
Type:
Read/Write
15
16
17
18
19
20
21
22
[Ref Units Char 1]
[Ref Units Char 2]
[Ref Units Char 3]
[Ref Units Char 4]
[Ref Units Char 5]
[Ref Units Char 6]
[Ref Units Char 7]
[Ref Units Char 8]
Selects up to 8 characters (from the ISO 8859-1 character set) to use
for the Reference units on the Process Display.
Parameters 15…22 can also be configured using the “Edit Ref Text”
selection in the HIM Setup tab.
Default:
72
(“H”)
Default:
122 (“z”)
Default:
32
(blank - no character)
Default:
32
(blank - no character)
Default:
32
(blank - no character)
Default:
32
(blank - no character)
Default:
32
(blank - no character)
Default:
32
(blank - no character)
Minimum: 32
Maximum: 255
Type:
Read/Write
23
[Fault Dspy Type]
Selects the type of display flash to be shown when a drive or
peripheral fault is detected.
Default:
0 = Flash Bklite
Values:
0 = Flash Bklite
1 = Flash None
Type:
Read/Write
24
[Alarm Dspy Type]
Selects the type of display flash to be shown when a drive alarm is
detected.
Default:
1 = Flash None
Values:
0 = Flash Bklite
1 = Flash None
Type:
Read/Write
Parameter
No. Name and Description
Details
