A158 [Energy Consumption]
Values Default 0 kWh
Min/Max: 0/65535 kWh
Display: Int-16 R/W
PowerFlex40
For the PowerFlex40, the custom firmware V52.0x, based on the firmware V1.07, has included
the new parameter A158, and modified the standard parameters D010, D022, D024 and A099.
D010 [Output Speed]
Values Default 0.0 RPM
Min/Max: 0/9999 RPM
Display: 0.01-1 Int-16 R
D022 [Motor Power]
Values Default 0.00 kW
Min/Max: 0.0/99.00 kW
Display: 0.01 Int-16 R
D024 [Heat Sink Temperature]
Values Default 0 degree
Min/Max: 0/120 degree
Display: Int-16 R
A099 [Speed Scaling Factor]
Values Default 30.0 RPM/Hz
Min/Max: 0.1/999.9
RPM/Hz
Display: 0.1 Int-16 R/W
A158 [Energy Consumption]
Values Default 0 kWh
Min/Max: 0/65535 kWh
Display: Int-16 R/W
PowerFlex 4/40 Custom Firmware 4
