-- (A)
BASE PINS
1C
1NO
1NC
2C
2NO
2NC
(9) --
+ (B) (6) +
17 VDC MIN.
CONTROL TERMINALS
TYPES 13, 22 & 23 TYPE 42RL
#63--66 OR #63--64 CONTROL TERMINAL CONNECTIONS
(A) --
BASE PINS
2C
2NO
2NC
1C
1NO
1NC
-- (7)
(B) + + (4)
CONTROL TERMINALS
TYPES 13, 22 & 23 TYPE 42RL
#63--67 OR #63--65
CONTROL TERMINAL CONNECTIONS
CAUTION: CUSTOMER POWER SUPPLY MUST NEVER BE DIRECTLY CONNECTED
ACROSS OPEN COLLECTOR TERMINALS.
1C
1NO
1NC
2C
2NO
2NC
CONTROL TERMINALS
TYPES 13, 22 & 23 TYPE 42RL
-- (A) (9) --
+ (B) (6) + 17 VDC
MIN.
#63--66
#63--64
RESISTOR
1K Ω, 1W for 20 Ma. Min.
560 Ω, 2W for 30 Ma. Min.
OPTO-ISOLATOR
INTERFACE
#63--66 OR #63--64
TYPICAL INTERFACING
(7) --
2C
2NO
2NC
1C
1NO
1NC (4)+
CONTROL TERMINALS
TYPES 13, 22 & 23 TYPE 42RL
#63--67 OR #63--65
TYPICAL LOGIC INTERFACING
#63--67 OR #63--65
TYPICAL COUNTER INTERFACING
#63--67
#63--65
PULL UP
RESISTOR
LOGIC INPUT
+5V (UP TO 30
VDC MAX.)
--
+
CUSTOMER LOGIC
TTL,R TL, DTL,CMOS
(7) --
2C
2NO
2NC
1C
1NO
1NC (4)+
CONTROL TERMINALS
TYPES 13, 22 & 23 TYPE 42RL
#63--67
#63--65
UP TO 24 VDC MAX.
250 MA MAX. CURRENT
--
CUSTOMER ELECTRO
MECHANICAL COUNTER
+
Publication PA--9207(A)
November 1992
Supercedes Publication PA--8202
