Rockwell Automation 20P PowerFlex DC Drive - Frame D Pulse Transformer Circuit Board User Manual
Page 6
6
Figure 3 Pulse Transformer Circuit Board Layout
XUV
XSW
XSW1
XCD_IO
XUVW
XCD
XR
XSPF
S3
78 79 35 36 75 76 81 82 U2 V2
X4 X5 X6
XTA
TR2
TR1
T1
T4
T2
T5
T3
T6
PE
XP1
XP2
KG1
KG4
KG2
KG5
KG3
KG6
KG01
KG04
KG02
KG05
KG03
KG06
T01
T04
T02
T05
T03
T06
XCT
S4
Components shown within dashed lines are only on
the pulse transformer board for regenerative drives.
T15
Tightening torque:
1.0…1.2 N•m
(9…10.5 lb•in)
