Page 2
2
Rockwell Automation Publication 20P-IN058B-EN-P - September 2012
PowerFlex DC Drive Frame D Terminal Adapter Kits
What This Kit Includes
This kit contains one of the following:
AC input 10 x 100 mm terminal adapter kit (SK-20P-S726171)
(see
Figure 1
on page
3
)
• Terminal adapter bars (3)
• M12 x 10 mm hexagonal nuts (6)
• M12 x 50 mm hexagonal bolts (6)
• M12 flat washers (18)
AC input 5 x100 mm terminal adapter kit (SK-20P-S726172)
(see
Figure 2
on page
4
)
• Terminal adapter bars (3)
• M12 x 10 mm hexagonal nuts (6)
• M12 x 50 mm hexagonal bolts (6)
• M12 flat washers (18)
DC output 10 x100 mm terminal adapter kit (SK-20P-S726173)
(see
Figure 3
on page
5
)
• Terminal adapter bars (3)
• M12 x 10 mm hexagonal nuts (6)
• M12 x 50 mm hexagonal bolts (6)
• M12 flat washers (18)
Tools That You Need
• Torque wrench
