WINGITS MASTER Basket WRBSN8 User Manual
Page 2

W8-01222013
MASTER Basket™ Details
INSTALLED DIMENSIONS PROJECTION OFF WALL
WIDTH
DEPTH
Corner Basket
6” (152 mm)
6” (152 mm) 1.5” (38 mm)
Rectangular Basket
5” (127 mm)
8” (203 mm) 1.5” (38 mm)
MASTER Basket™ Materials
Wall Flange
1/16” (1.6 mm) stamped stainless steel plate
Mount Bracket
Cast stainless steel bracket and insert cap with rubber gasket, to seal in the mounting screw
Structural Rim
1/2” (12.5 mm), stainless steel, thickness 0.25” (6.25 mm). Structural rim runs complete length of basket perimeter.
Finish
Stainless steel is polished to a chrome mirror appearance
MASTER Anchor™ Materials
Screws
8-32 x 3.5” stainless steel machine screw
Faceplates and Wings
Fire retardant structurally engineered plastics
Tape
3M double sided watertight tape
Specifications
Installation
Install the MASTER Basket™ with the supplied MASTER Anchors™ W
ING
I
TS
®
MASTER Anchors™ WCBPS6 (6”), WCBSN6 (6”) or WRBPS8(8”), WRBSN8(8”)
Installation of the MASTER Basket™ with the MASTER Anchor™ is GUARANTEED!
714 Fifth Avenue, PO Box 97, Bradley Beach, NJ 07720 USA
Toll Free: 877-894-6448 • Phone: 732-869-4466 • Fax: 732-869-9474
www.wingits.com • [email protected]
W
ING
I
TS
®
5”
