PFC Micro Design Guide
03-000048 rev A Vicor 800-735-6200 Westcor Division 408-522-5280 Applications Engineering 800-927-9474 Pg. 17
O UTPUT
VI-200/VI-J00 Modules
Parameter MIN. TYP. MAX. UNITS NOTES
Setpoint Accuracy* 0.5 1 % of Vnom
Load/line Regulation 0.05 0.5 % LL to HL, 10% to Full Load
Load/line Regulation 0.2 0.5 % LL to HL, No Load to 10%
Temperature Regulation 0.01 0.02 %/°C Over rated temp.
Long Term Drift 0.02 %/K hours
Output Ripple & Noise:
≤ 10V out
100 mV 20 MHz bandwidth
> 10 V out 1.0 % Vout 20 MHz bandwidth
Voltage Trim Range
VI-200/VI-J00 Slots 50-110 % V out
± 10% on 10-15 Vout
Total Remote Sense Compensation 0.5 Volts Autosense. See pg.6 & 11
OVP Set Point 1
115 125 135 %Vout Recycle Power
Current Limit 105 115 125 % of I max Auto Recovery
Short Circuit Current 1 20 (1052) 130 %
Overtemperature Limiting Not available on VI-J00
* For special and adjustable voltages, maximum setpoint accuracy is 2% of Vnom.
1 131% Nominal for Booster Modules. No OVP for VI-J00
2 VI-J00 modules only.
Maxi, Mini and Micro series modules
Parameter MIN. TYP. MAX. UNITS NOTES
Setpoint Accuracy* ±0.5 ±1 % of V
NOM
Load/line Regulation ±0.08 ±0.45 ( ±7) % of V
NOM
0% to 100%
Temperature Regulation 0.002 0.005 %/°C -40 to 100°C
Long Term Drift 0.02 %/K hours
Output Ripple and noise:
≤ 10V out
100 mV 20 MHz bandwidth
> 10 V out 1.0 % Vout 20 MHz bandwidth
Voltage Trim Range
Maxi/Mini/Micro Slots 10-110 % Vout Preload may be required.
Total Remote Sense Compensation 0.5 Volts Autosense. See pg.6 & 11
OVP Set Point 112 135 % of V
out
Recycle power
Current Limit 102 115 135 % of I max Auto Recovery
Overemperature Limiting Not available
* For special, adjustable voltages and 48Vdc outputs, maximum setpoint accuracy is 2% of Vnom.
Note: See individual module datasheets for specific module specifications.
E NVIRONMENTAL
Storage Temperature -40°C to +85°C
Operating Temperature
Full Power -20°C to +45°C ( -40oC to +45oC option w/ MI chassis)
Half Power -20°C to +65°C ( -40oC to +60oC option w/MI chassis)
Altitude Derate 2.6% total output power for each 1,000 ft to a maximum
operating altitude of 15,000 ft. Non-operating storage maximum
altitude is 40K.
Shock and Vibration Mil-STD 810 (MI rugged chassis only)
Humidity 0 to 95% non condensing
Product Weight 5.2 lbs. (2,4 kg)
Dimensions 1.86" H (47,3mm) x 5.06" W (128,5mm) x 10.40" L (264,1mm)
Warranty** 2 years limited warranty. See vicorpower.com for complete warranty
statement.
** Opening, repairing or modifying the unit will void the warranty. If you have any problem with the power supply,
please contact Customer Service at 1-800-735-6200. If the unit needs to be returned for inspection/analysis, an
RMA number will be issued. All units must have a RMA number prior to return.
