VisiDoc-It Imaging System 2
System Introduction
The VisiDoc-It Imaging System is designed for researchers who already have a transilluminator in the lab.
Configurations include a compact hood or camera stand. The compact hood fits on top of UVP’s High
Performance and Benchtop Transilluminators. The VisiDoc-It System provides simple documentation of
fluorescent and non-fluorescent gels, membranes, blots, film plates and assays with the ability to save
images to a USB storage device for later quantitative analysis.
VisiDoc-It Components
Refer to the packing slip and pictured components for parts included with the system.
VisiDoc-It with Hood
Transilluminator (check the
packing slip to determine if
the system includes a
transilluminator)
Hood (with handles) fits over
the filter area on the
transilluminator
Camera and Lens Kit
EtBr Filter is mounted in the
top of the hood
8” LCD Touch Screen
USB Drive System Processor
