Manual BioLite MultiSpectral Light Source
4
System Components
Refer to the packing slip and schematic shown below for specific parts and components included with the
BioLite MultiSpectral Light Source.
Specifications
Color Temperature:
3250°K
Bulb Type:
150 Watt Halogen Type EKE
Ferrule Dimension:
0.718 inch (18.2 mm)
Physical Dimensions:
Height
8.75 Inches (22 cm)
Width
7 Inches (18 cm)
Depth
10 Inches (25 cm)
Weight
9 pounds (4 kg)
Power Requirements:
115V
3 Amps max, 50/60 Hz
230V
1.5 Amps max. 50/60 Hz
100V
3 Amps max, 50/60 Hz
Master Power Switch
Light Intensity
Selector Knob
Excitation Filter
Cartridge
Fiber Optic Port and
Cable
