Step 6, Step 7 – TruXedo Deuce User Manual
Page 6

___ 6 ___
STEP 6
Rotate release levers to the left before connecting outside tie-bars.
Rotate both levers to
the position as shown.
STEP 7
7A
7B
7c
7d
Connect driver and passenger short tie-bars as shown below.
Remove anti-spin
tape
Position both release levers to the left before attaching outer tie-bars, see step 6.
Connector End
Ball Socket
Rotate Tie-bars into
position as shown
Driver side shown,
repeat procedure for
passenger side
Left
