STEP 2-A

Attach driver and passenger side underbody rails, see note 1 & 2 for installation hints.

COMPRESS SEAL

ADJUSTABLE

CLAMP

FOR BEST CLAMPING

MOUNT CLAMP HIGH

AS POSSIBLE

Note 1

Compress Block Seal

WhiLE CLAMPiNG PRESS DOWN

30 1/4”

Front Bulkhead

Driver’s Side

30 1/4”

Front Bulkhead

Passenger Side

Compress Block Seal

Note 2

___ 3 ___

STEP 3

Passenger’s Side

Rail Assembly

Driver’s Side Rail

Assembly

Position driver and passenger rails.

Clamps

Level
