VERTICAL STACK VS-IOM-00 01-19-09
INSTALLATION AND
MAINTENANCE INSTRUCTIONS
6 f o 2 e g a P
2. ELECTRICAL
2.1 All electrical connections are to be made in accordance with the National Electric
Code, state and local codes, bylaws, ordinances or the authority having jurisdiction.
Make all electrical connections inside the electric junction box by carefully
following the wiring diagram.
2.2 Adhere strictly to the electrical wiring diagram in order to avoid damage and/or
personal injury.
2.3 When the thermostat and fan switch are field supplied, the following are the minimum
electrical ratings:
- Thermostat (valve load) = 0.1A @ 115V
(0.05A @ 230V)
- Fan Motor(s) @ full load amps, FLA (@115V):
3. INSPECTION
3.1 Check that the electrical power to the unit is OFF.
3.2 Check that the disconnect switch mounted on the internal electric box is OFF.
3.3 Check drain pan for foreign materials.
3.4 Check fan and motor for foreign materials and freedom of movement.
3.5 Check that all wiring is properly terminated and the internal electric junction box is
properly covered.
3.6 Check that the filter is clean and secured in position.
SIZE FLA (Amps)
03 1.3
04 1.4
06 2.0
08 2.9
10 4.0
12 3.7
STANDARD MOTOR
SIZE FLA (Amps)
03 1.6
04 1.6
06 2.9
08 3.5
10 4.3
12 4.0
HIGH STATIC MOTOR
