5. ELECTRICAL
5.1
All electrical connections are to be made in accordance with the National Electric
Code, state and local codes, bylaws, ordinances or the authority having jurisdiction.
Make all electrical connections inside the internal electric junction box by carefully
following the wiring diagram.
5.2
Electrical wiring diagram is located inside the unit’s enclosure. Adhere strictly to it in
order to avoid damage and/or personal injury.
6.
GENERAL PRECAUTIONS
After completing the installation, recheck the following:
6.1
The drain pans, fans and motors are clean of all foreign material.
6.2
All electric wiring is properly routed, secured and capped.
6.3
The filter is clean and secured in its position.
7.
INITIAL START-UP
7.1
Chilled/Hot Water Unit
7.1.1
Ensure that the main distribution system is operable (i.e. both supply and return piping
are under full operating pressure).
7.1.2
Open the unit’s isolating ball valves (optional) and observe that no leaks are evident.
7.1.3
Open the 2-Way or 3-Way Valve (optional) manually by moving the lever provided on
the valve motor thus pressurizing the unit’s coil.
7.1.4
Remove the cap of the air-vent valve and depress the needle to release the trapped air.
Continue until only liquid is coming through and then re-cap and secure tightly.
