Steel
Door Panel
Dimensions
Comp 6 2014 (BOOK SIZE) 6.9
6/8 Steel Entry Doors
B
A
23-7/8”
4-1/8”
7-7/8”
D
25-1/2”
4-1/2”
21-1/2”
E
4-1/2”
9-1/2” C
Size A B C
2/8 31-31/32” 4-3/64” 4-15/64”
2/10 33-31/32” 5-3/64” 5-15/64”
3/0 35-31/32” 6-3/64” 6-15/64”
4 LIte 4 Panel Flush
(444, 2206)
(Slab - HD210, HD254 & TS210, TS254)
Daylight Opening: 21-1/8" x 5"
(93 sq.in.)
Height D E
6/8 79-1/4" 9-5/16"
7/0 83-1/4" 13-5/16"
E
7-15/16"
25-1/2"
21-1/2"
F
C 9-1/2"
D
A
B 9-15/16"
4-1/16"
2 Lite 4 Panel Flush
(Glass - 296, 996, 0806)
(Slab - HD210, HD254, & TS210, TS254)
Size A B C
2/8 31-31/32" 4" 4-15/64"
2/10 33-31/32" 5" 5-15/64"
3/0 35-31/32" 6" 6-15/64"
23-1/2"
Height D E F
6/8 79-1/4" 4-5/32" 9-5/16"
7/0 83-1/4" 7" 13-5/16"
Daylight Opening: 6-15/16" x 4-15/16" (per lite)
(68 sq.in. total)
