Version 1.1 - Page 12
The strain relief (liquid tight cord connector) is suitable for flexible cord with a diameter of
10mm. We recommend using S-W or S-J cord, minimum 16 AWG.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DISCONNECT SUPPLY
MAINS BEFORE SERVICING.
The supply line used to feed power to the feeder circuit should be rated for outdoor use.
Refer to the NEC and local codes as applicable.
WARNING: To prevent the risk of electric shock and equipment damage, disconnect any
and all power supply to the enclosure before installing, maintaining or trouble shooting this
product or any products inside the enclosure.
Electrical Connection
Before running electrical power to the device, you must first install the strain relief bushing
that comes included with the enclosure. Be sure to install the strain relief bushing with the
gasket of the outside of the enclosure. Also, the strain relief bushing nut should be tightened
snugly by hand. Once the bushing has been tightened by hand, use a wrench to apply an
additional quarter turn for final tightening. Do not over tighten the nut – over tightening the
nut can cause the strain relief bushing to crack. Refer to figure 8.
The electrical wiring should be routed through the strain relief bushing to the terminal block.
Refer to wiring diagram – figure 9.
