54
Regency Bellavista™ B41XT Gas Fireplace
INSTALLATION
14) To install the top panel - line up the 2 tabs on the panel with the
corresponding bracket clip on the inside top of the unit and slide into
place (see below).
16) Re-hang the screen doors.
15) The full screen doors are stabilized by 2 magnets which are attached
to a bracket. Install the bracket to the fl ange at the base of the unit
using 2 screws. There are 2 hole locations on the bracket to accom-
modate fl ush wall & thicker fi nishing materials.
Location of bracket clips in unit.
Final Screen Door Install
Thicker Finishing
Screw Location
Flush Wall
Screw Location
