Assembly
Attach the paper wire extension
Attach the paper wire extension as shown
in the illustration below.
Attach the paper tray
Attach the paper tray. Make sure the wide
pins on the paper tray inserted firmly into
the pockets on the top edge of the
machine.
Attach the output paper support
Attach the output paper support.
Paper Wire
Extension
Paper Tray
Output
Paper
Support
