Chapter 1. Product
1.1. Overview
Robustel RobustLink is an industrial-grade centralized management and administration system for Robustel
GoRugged series router & gateway, including R3000, M1000 XP and M1000 Pro V2.
RobustLink consists of three parts: Web Server (Apache), Agent Server and MySQL. Users can configure relevant
parameters of RobustLink via Web Server; Agent Server is platform for data communication which will process all the
data coming from slave device, or via vise; MySQL is a database used to store parameters and transaction data. Three
parts should work together to ensure all the functions of RobustLink.
RobustLink allows user to monitor, configure and manage large numbers of remote devices on a private network over
the web.
It mainly has following features:
Remote Monitoring
Remote Configuration
Remote Firmware Updates
Data Forwarding
Number of Devices: 1000+
Management: Web
1.2. Selection and Ordering Data
Please refer to corresponding RobusLink datasheet.
Local /Remote
PC/IPAD/iPhone
Connect to Web
Server via port
80/443
Open port numbers:
31009/31000/31001
Open port number: 3306
Connect to Agent
Server via 31001
Connect to
MySQL via 3306
Connect to
MySQL via 3306
RobustLink
Open port numbers:
80/443
M1000 Pro V2
/M1000XP/R3000
Connect to Agent
Server via port
31000
Web Server
Agent Server
MySQL
