Agent Server
Item Description Default
Agent-Server Address
Set IP address of Agent Server. For example, when Agent Server is installed
in the same IP address of MySQL and Apache, user can enter “localhost”,
“127.0.0.1” in this filed; If Agent Server is set away from MySQL and
Apache, not in the same IP address, user should enter the IP address of
Agent Server. For example, when Agent Server is installed in remote server
(PC), its IP address is 120.197.58.89, and then we shall enter
“120.197.58.89” in this filed.
Localhost
Port Set a local port number of Agent server. 31001
Protocol
Set transport layer protocol which device used to connect to Agent Server.
Note: can’t be selected yet.
tcp
Timeout(s)
Set timeout when slave device connect to Agent Server. For example, if
“Timeout” is set as “30”, when device keep on connecting Agent Server,
after 30 seconds but still can’t succeed to connect to Agent Server, log
information will show connection timeout.
Data range is from 5 to 60 seconds.
30
Connect Click to update settings to Agent Server after above settings. /
3.14. ADMINISTRATION -> MySQL
This section allows user to set parameters of MySQL.
