Robustlink Central Manager User Guide
RT_UG_RobustLink_v.1.0.0 12.12.2013 13 / 43
Confidential
Data By Modbus Address (Modbus TCP)” and define a range of Modbus Address basing on the settings of “Port”,
“Modbus Start Addr” and “Modbus End Addr”, then RobustLink will forward data from different devices to one
port or different ports according to the range of Modbus Address. It depends on the users whether use one port or
different ports to accept data from different range of Modbus Address.
3.5. CONFIGURATION -> XML
This section allow user to import configuration file of R3000 for batch configuration. This function only available for
R3000.
XML
Item Description Default
Records Per page
Selected from “10”, “25”, “50”, “all”, user can set how many devices are
wanted to show in one page.
25
Search
User can enter characters to search specific information. For example, when
enter “R3000”, all information relevant to R3000 will show up.
Null
Index Show the index of each device Null
Status
Show the status of devices. If device login to RobustLink, it will show
“
”, or it will show “ ”.
Null
Device ID Show the ID of device. Null
Device Type
Show the type of device. For example, “M1000 XP”, “M1000 Pro V2” or
“R3000”.
Null
IMEI Show the IMEI number of device. Null
Version Show the firmware version of device. Null
Click to select the device you want to do batch configuration. Null
Reboot devices after
configure
Click to reboot device after configuration. Null
Browse Click to upload configuration file (XML). /
