Robustlink Central Manager User Guide

RT_UG_RobustLink_v.1.0.0 12.12.2013 38 / 43
Confidential

6. Run Hercules (download via link

http://www.hw-group.com/products/hercules/index_en.html

) --> go to tab

“TCP Client” --> enter IP address and Port number of above TCP server which has been created in RobustLink -->
click “Connect”. If succeed to connect to the TCP Server, in this document, it will show up message

“Connecting to 113.113.49.201 …

Connected to 113.113.49.201”.

7. Run Terminal exe (download via link

https://www.box.com/s/67a68jraki9k1r0lijuz

) --> select the same serial

port settings of R3000: COM 1, Baud Rate 115200, Data Bits 8, Parity none, Stop Bits 1, Handshaking none -->
click “Connect” --> enter characters like “123456” --> click “Send”.
