RKI Instruments SDM-2012 Standalone Configuration - Manual (Page 8)

3 • Specifications
Specifications
Table 1: SDM-2012 Specifications
Input Power 12 VDC
NOTE: AC Adapter with 100 - 240 VAC, 50/60 Hz,
0.6A input and 12 VDC, 1.2A output provided as
standard.
Environmental Conditions • For Indoor Use Only
• -10° C to 40° C, below 80% Relative Humidity, Non-
Condensing
Applicable Instruments GX-2012 and Gas Tracer
Memory Capacity 64 KB
Maximum Record Size 256 bytes
Maximum Number of
Records Saved 200
Number of Calibration Gas
Cylinders Up to two calibration gas cylinders per bump test or
calibration at a time
Standard Accessories • AC Adapter
• USB Flash Drive
• Single Module Data Viewer Software
• SDM Docking Station PC Controller Software
• Inlet Air Filter
• Instruction Manual
• 10 Foot Long Exhaust Tube
• Two 3 Foot Long Tubes for GAS 1 and GAS 2
Fittings
• 3 T-Fittings for PC Controlled Configuration
• USB Cable, Type A to Type B
