Control Panel • 12
CAL
S
• Initiates a calibration
• Cancels a calibration
• Clears data from docking station
memory (when used with COPY
button)
• Moves up a list of parameters
• Increases an adjustable parameter
Indicates status of a calibration
in progress
EDIT
ENTER • Puts docking station into various
edit modes
• Makes a displayed parameter
editable
• Escapes or cancels an operation
• Turns off connected instrument
(when used with POWER button)
n/a
COPY • Copies data to a USB flash drive.
• Clears data from docking station
memory (when used with CAL
S
button)
• Indicates amount of docking
station memory used
• Indicates status of copying
function
• Indicates the result of a copy
operation
POWER • Turns on the docking station
• Turns off the docking station
• Turns off connected instrument
(when used with EDIT ENTER
button)
n/a
Table 2: Control Button Functions
Control
Button
Control Button Function(s)
Control Button LED
Function(s)
