GuardNVR Installation Manual 49
Version 4.4 Series
are using port 80 as the default. When you change to a new value, you must now enter
http://xx.xx.xx.xx:yy where yy is the new TCP port setting.
4.3.3 Changing remote desktop port
GuardNVR ships with the default remote port set to 3389 that should be forwarded in your
router in order to be able to access the unit via remote desktop. If this port needs to be
changed, follow the steps below.
1. Logon as Administrator.
2. Double Click the Support folder from the Windows desktop and select RegEdit by
double clicking.
3. Proceed through the following path HKey_Local_Machine->System->Current
Control Set->Control->Terminal Server->Winstations->RDP-TCP Select RDP-
TCP.
4. After selecting RDP-TCP, scroll down the list in the right pane until you come to Port
Number. Double click Port Number to Edit.
5. On the pop up screen select Decimal under Base and then enter the desired value in the
Value box.
6. Click OK to confirm.
7. Be sure to enter this value in the port forwarding section of your router.
A system reboot is typically required after making registry changes. Check also your
firewall settings. The new port must be added to the exception list.
4.4 GuardNVR power on after power failure
To adjust the GuardNVR server to power on again automatically after the power failure, you
must configure the BIOS to go to previous state after power loss. This can be done by entering
the BIOS during the initial stage of the machine booting.
4.5 Configuring audio over the Internet
GuardNVR supports specific audio functions for the following brands:
Axis – Listen in and speak:
o M1031-W, M1054
o P1311, P1343(-E), P1344(-E), P1346(-E), P3301(-V), P3304(-V), P3343(-
V/VE), P3344(-V/VE), P5534
o Q1755, Q1910(-E), Q7401
By default, audio is supported only for Q7401. For the other models mentioned above,
contact support as a small extra configuration is needed.
