Quadrox QGuard Installation Manual - Manual (Page 18)

GuardNVR Installation Manual 18
Version 4.4 Series
To adjust the Date and time manually follow the steps below:
In the Control Panel, in the left upper corner click the ‘Switch to Classic view’ link.
When in classic view, select Date and Time from the right-hand list.
On the Date and Time properties dialog, select the ‘Date & Time’ tab (XP) or click
‘Change Date & Time’ (Vista).
When in the ‘Date & Time’ menu, set the correct date and time.
Click OK to save the ‘Date and Time’ changes.
2.3.4.2.2 Time synchronization
Synchronize your computer time with the atomic clock on the Internet for the best time
accuracy.
Optionally the installer/user can configure a GuardNVR to synchronize its time and date
automatically on a regular basis using a so-called ‘Time Server’. These special servers exist
often on bigger corporate networks or on the Internet. To set this up, follow the steps below:
Click Settings -> Control panel.
In Control Panel, in the left upper corner click the ‘Switch to Classic view’ link.
When in classic view, select Date and Time from the right-hand list.
On the Date and Time properties dialog, select the tab ‘Internet Time’ (XP) or click
‘Change Settings’ (Vista).
Check the box ‘Synchronize with an Internet time server’.
Enter the name or IP-address of a known time server into the 'Server' edit box. Note
that when using a name in the IP-address settings of the GuardNVR server, a correct
DNS IP-address should be supplied. Otherwise this name will never be resolved/found.
If you use an IP-address there is no need to provide a DNS server.
Click OK to save the ‘Internet Time’ changes.
The default Internet Time Server is time.windows.com; however you can use other
time servers for synchronization, such as those provided below:
time.nist.gov (IP-address: 192.43.244.18)
utcnist.colorado.edu (IP-address: 128.138.140.44)
Make sure that there is no computer in the network with the same IP address.
2.3.5 Changing keyboard settings
Follow the steps below:
In Control Panel, in the left upper corner click the link ‘Switch to Classic view’.
When in classic view, select Regional and Language Options from the right-hand list.
In the Regional and Language Options dialog, select the ‘Languages’ tab.
When on the ‘Languages’ tab, click the ‘Details’ button. The following window
appears:
