Precision Turbo and Engine NLR AMS-1000 Boost Controller User Manual
Page 9

9
Setting Activation Hold and Clutch Reset Style
The Activation Hold function when Programmed with a value greater than 0.00 will Delay the
release of the Activation Input. i.e.—If the user is using a Wide Open Throttle switch to control the Acti-
vation. A Delay could be used to keep the system from re-setting if the throttle is lifted for a short period
of time.
If the Clutch Reset Style is ON all Timers and Both channels will be RESET if the Clutch Input is
Active (even if the Activation Signal is ON). If the Clutch Reset Style is OFF the system will only RESET
when the Activation signal is removed.
Press the OPTION button.
1
Press the NEXT button.
2
Press TIMER button.
3
4
Press the ACT,HOLD button.
5
ESC, Exit
and do
NOT save
new value
SAVE, Exit
and Save
new value.
Adjust Value.
6
Press the BACK button to exit.
Use the BACK button to Return
to the Main Screen.
Setting Clutch Reset Style…
Follow Steps 1 through 3 above.
4
Press the RESET button to
Toggle Clutch Reset On/Off.
5
Press the BACK button to exit.
Use the BACK button to Return
to the Main Screen.
Click for Index.
Back
Next
NOTE—Target Psi is the amount applied to the waste gate and is NOT the actual Manifold Boost Psi!
