Specifications
Normal Operating Voltage— 10 to 16 volts (Controller will function down to 7 volts, Solenoids
need a minimum of 10 volts for proper operation).
Maximum Current— 5 Amps for each Solenoid Output.
MAP Sensor Input— 0 to 5 volts.
GPS Input— 0 to 5 volts.
Overall
Height—
.975”
Overall
Width—
2.850”
Overall
Length—
4.350”
3.850”
2.450”
Click for Index.
Back
Next
NOTE—Target Psi is the amount applied to the waste gate and is NOT the actual Manifold Boost Psi!
