Commissioning Page 6 of 11
Commissioning
Initialising the system
After the system has been wired up, be sure to check over the connections against the wiring diagrams
provided before powering up for the first time. When the system is powered up for the first time the keypad
will bleep 3 times a second. This indicates that the keypad is waiting to be initialised. The red and amber
LEDs will be off and the green LED will be flashing.
• Press the bell button
(The unit will stop bleeping and the green LED flashes faster)
• Enter your chosen 6 digit programming code* and press the bell button.
(The green LED will flash faster still)
• Confirm your chosen programming code by entering the same 6 digit code and pressing the bell
button.
(The green LED goes out and the unit will acknowledge that the programming code has been accepted by bleeping twice
after a 2 short pause. All the LEDs are now on)
* Note that the programming code SHOULD NOT have the sequence of numbers 1234 in, as this is the
default user code
What is the next step?
The keypad/s should now work with the user code 1234. The programming code you just entered will now
let you into programming mode, where additional alterations can be made. The system will work according
to the default settings (See Operation – TOUCHLOCK).
Check the system operates correctly using the default settings.
• Type in the user code 1234
(The green LED will flash on the keypad/s and the lock output will activate for 7 seconds)
• Type in the programming code you set
(There will be 2 beeps to confirm that the correct programming code has been entered and the green LED will flash)
• If a buzzer/bell is connected, press the bell button.
(The buzzer/bell will sound for as long as the bell button is held down on the keypad)
• If an exit/remote button is connected, press it.
(The lock output will activate for 7 seconds and the keypad will beep once)
• Check that the keypad beeps each time a number button is pressed on the keypad.
• Check that lockout is disabled by pressing more than 20 buttons in a sequence that does not include
the user or programming code.
Reset procedure
The TOUCHLOCK will remember its settings in the event of a power cut. To return the unit to the factory
default settings, a data reset must be done. For a list of the factory settings, see initialising the unit. The
procedure for doing this is outlined as follows:
-
Turn off the power to the unit.
-
Disconnect the white wires and ensure that the green and grey wires are not shorting together.
-
Hold down the ‘3’ button on the keypad and re-administer power to the unit. When the power is
applied, release button ‘3’.
- 3 beeps will indicate that the unit has successfully data reset
The keypad should now beep 3 times a second. (The green LED will be continually flashing)
NOTE: If the correct programming procedure is not followed the red LED will flash and the keypad will
exit the procedure.
