About Page 3 of 11
About
TOUCHLOCK compact stainless steel is a single door, single keypad access control system. The keypad is
suitable for internal and external installations. The keypad is suitable for high use applications. The unit is
self contained with the control unit, or decision making electronics, housed within the keypad itself. The
unit can be powered by both ac and dc 12V power supplies.
The output to the electric release is 12Vdc solid state limited to 500mA continuous and 750mA
intermittent (7 seconds).
Features
The unit can be programmed with up to 50 user codes containing 4 - 8 digits each. An exit button may also
be connected to the unit.
There are two outputs, one for the electric lock and one that can be used for a door bell/duress alarm see the
TOUCHLOCK programming guide.
All system settings and the user codes are changed via the keypad.
Any number of TOUCHLOCK systems may be installed on a site.
Switch2 (Sales code 405-321/405-500) is an alternative product that has a separate keypad and control unit.
Switch2 has two keypad capability for two way access control, voltage free relay contacts for the electric
lock, and increased functionality. For more information contact our technical helpline.
Contents in box
For Stainless steel keypad
TOUCHLOCK keypad stainless steel
Instructions for keypad
Fitting kit for keypad
For Stainless steel keypad kit
TOUCHLOCK keypad stainless steel
Instructions for keypad
Fitting kit for keypad kit
12V 1Amp AC transformer
12V DC fail locked release kit
Mortice fitting for release
Rim fitting for release
