Wiring
Read in, read out
When using in and out readers, users may be picked up by both readers as they move through the door which
will reduce the reliability of any roll call or anti-passback application. Ensure that sufficient spacing is provided
between these readers for optimum range and reliability.
Positioning readers
Hands free readers should be positioned so that their transmission fields do not overlap.
(see table on back page for typical hands free ranges)
For optimum keyfob battery life please choose your reader location carefully to
avoid placing it within hands free range of work stations, rest or smoking areas.
You will see that the interface is mounted upside down in the housing.
This is to position the internal aerial away from other reader components and is intentional.
Interface Module
Reader Module
