Page 4: V-ne / v-ne-sd metr
76
M
RoHS
RoHS
M 12 x 1,5
8,5
13
16,5
15
6
1.255.1201.50
1.256.1201.50
M 16 x 1,5
8,5
13
20,5
19
8
1.255.1601.50
1.256.1601.50
M 20 x 1,5
9
14,5
25,5
24
8
1.255.2001.50
1.256.2001.50
M 25 x 1,5
10,5
16
30,5
28
8
1.255.2501.50
1.256.2501.50
M 32 x 1,5
11,5
17,5
38
36
8
1.255.3201.50
1.256.3201.50
M 40 x 1,5
11,5
18
48
46
8
1.255.4001.50
1.256.4001.50
M 50 x 1,5
13,5
20
60
55
8
1.255.5001.50
1.256.5001.50
M 63 x 1,5
14,5
21
75
70
8
1.255.6301.50
1.256.6301.50
PG 7
8,5
13
16,5
15
6
1.255.0701.11
1.256.0701.11
PG 9
8,5
13
20,5
19
8
1.255.0901.11
1.256.0901.11
PG 11
9
14,5
25,5
24
8
1.255.1101.11
1.256.1101.11
PG 13,5
9
14,5
25,5
24
8
1.255.1301.11
1.256.1301.11
PG 16
10,5
16
30,5
28
8
1.255.1601.11
1.256.1601.11
PG 21
11,5
17,5
38
36
8
1.255.2101.11
1.256.2101.11
PG 29
11,5
18
48
46
8
1.255.2901.11
1.256.2901.11
PG 36
13,5
20
60
55
8
1.255.3601.11
1.256.3601.11
PG 42
13,5
20
65
60
8
1.255.4201.11
1.256.4201.11
PG 48
14,5
21
75
70
8
1.255.4801.11
1.256.4801.11
V-NE
V-NE-SD
V-NE
V-NE-SD
V-NE / V-NE-SD
PG
Accessories
V-NE / V-NE-SD
Metr.
O-Ring Buna-N
Colors black (RAL 9005)
Protection IP 54 (V-NE)
IP 68 – 10 bar / IP 69K (V-NE-SD)
Operating Temperature - 20 °C – 80 °C (- 4 °F – 176 °F)
Material Polyamide, fiber reinforced
O-Ring Buna-N
Colors black (RAL 9005)
Protection IP 54 (V-NE)
IP 68 – 10 bar / IP 69K (V-NE-SD)
Operating Temperature - 20 °C – 80 °C (- 4 °F – 176 °F)
Material Polyamide, fiber reinforced
Number Number
AG GL H D
V-NE V-NE-SD
mm mm mm mm mm
without O-Ring
Number Number
AG GL H D
V-NE V-NE-SD
mm mm mm mm mm
without O-Ring
Dimensions and specifications may be changed without prior notice
Advice:
- Other colors upon request
- Please find more O-Rings on page 88
Advice:
- Other colors upon request
- Please find more O-Rings on page 88
