85
G
C
E
D
H
A
PG 9 50 45 37 4,3 29 1.306.0900.14
PG 11 50 45 37 4,3 29 1.306.1100.14
PG 13,5 56 53 44 5,5 35 1.306.1300.14
PG 16 56 53 44 5,5 35 1.306.1600.14
PG 21 68 68 55,5 5,5 43 1.306.2100.14
PG 29 74 70 60 5,5 52 1.306.2900.14
PG 36 93 88 72 6,5 68 1.306.3600.14
RoHS
O-Ring Buna-N
Accessories
FW-T PG
Operating Temperature - 20 °C – 95 °C (- 4 °F – 203 °F)
Material Polyamide
Protection IP 65
Colors grey (RAL 7011)
A C D E G H Number
mm mm mm mm mm
Dimensions and specifications may be changed without prior notice
Advice:
- Metric threads with O-Ring thread seal available
