Northern Connectors Hummel Industrial Cable Gland Accessories - Manual (Page 23)

IG AG
D
GL H
AG
IG
H GL
95
M
RoHS
RoHS
M 16 x 1,5 PG 9 6 10,5 20 1.039.1609.01
M 20 x 1,5 PG 11 6,5 12,5 22 1.039.2011.01
M 20 x 1,5 PG 13,5 6,5 12,5 22 1.039.2013.01
M 20 x 1,5 PG 16 6,5 12,5 24 1.039.2016.01
M 25 x 1,5 PG 16 6,5 12,5 28 1.039.2516.01
M 25 x 1,5 PG 21 6,5 14,5 30 1.039.2521.01
M 32 x 1,5 PG 29 7 16 39 1.039.3229.01
PG 9 M 16 x 1,5 6 10,5 20 1.039.0916.01
PG 11 M 20 x 1,5 6,5 12,5 22 1.039.1120.01
PG 13,5 M 20 x 1,5 6,5 12,5 22 1.039.1320.01
PG 16 M 25 x 1,5 6,5 14,5 27 1.039.1625.01
M 16 x 1,5 NPT 1/2" 6 17 24 1.171.1612.50
M 20 x 1,5 NPT 1/2" 6 17 24 1.171.2012.50
M 25 x 1,5 NPT 1/2" 7 8 30 1.171.2512.50
M 25 x 1,5 NPT 3/4" 7 19 30 1.171.2534.50
M 32 x 1,5 NPT 1" 8 25 40 1.171.3210.50
M 32 x 1,5 NPT 1 1/4" 8 25 46 1.171.3254.50
PG 11 NPT 1/2" 6 16,7 24 1.171.1112.01
PG 13,5 NPT 1/2" 6,5 17 24 1.171.1312.01
PG 16 NPT 1/2" 6,5 16,5 24 1.171.1612.01
PG 21 NPT 1/2" 7 8 30 1.171.2112.01
PG 21 NPT 3/4" 7 17 30 1.171.2134.01
PG 29 NPT 1" 8 12 40 1.171.2910.01
Material Nickel plated brass
Material Nickel plated brass
RE-Ms PG
Accessories
RE-Ms Metr., PG
AG IG GL H D Number
mm mm mm mm
AG IG GL H D Number
mm mm mm mm
Dimensions and specifications may be changed without prior notice
O-Ring NBR
