Page 10
82
GL
H
AG
L
IG
M
RoHS
M 16 x 1,5
M 16 x 1,5
8
23
28,5
5
19
1.316.1600.50
1.316.1601.50
M 20 x 1,5
M 20 x 1,5
9
30,5
35
7
24
1.316.2000.50
1.316.2001.50
M 25 x 1,5
M 25 x 1,5
11
40
49
10
33
1.316.2500.50
1.316.2501.50
PG 9
M 16 x 1,5
8
23
28,5
5
19
1.316.0900.11
1.316.0901.11
PG 13,5
M 20 x 1,5
9
30,5
35
7
24
1.316.1300.11
1.316.1301.11
PG 21
M 25 x 1,5
11
40
49
10
33
1.316.2100.11
1.316.2101.11
M 16 x 1,5
PG 9
8
23
28,5
5
19
1.315.1600.50
1.315.1601.50
M 20 x 1,5
PG 13,5
9
30,5
35
7
24
1.315.2000.50
1.315.2001.50
M 25 x 1,5
PG 21
11
40
49
10
33
1.315.2500.50
1.315.2501.50
M 32 x 1,5
PG 29
11
51,5
60
14
42
1.315.3200.50
1.315.3201.50
PG 9
PG 9
8
23
28,5
5
19
1.315.0900.11
1.315.0901.11
PG 11
PG 11
8
27
31,5
6
22
1.315.1100.11
1.315.1101.11
PG 13,5
PG 13,5
9
30,5
35
7
24
1.315.1300.11
1.315.1301.11
PG 16
PG 16
10
32,5
37,5
8
27
1.315.1600.11
1.315.1601.11
PG 21
PG 21
11
40
49
10
33
1.315.2100.11
1.315.2101.11
PG 29
PG 29
11
51,5
60
14
42
1.315.2900.11
1.315.2901.11
NPT 3/8"
PG 9
15
23
28,5
5
19
1.315.3800.70
1.315.3801.70
NPT 1/2"
PG 13,5
13
30,5
35
7
24
1.315.1200.70
1.315.1201.70
NPT 3/4"
PG 21
13
40
49
10
33
1.315.3400.70
1.315.3401.70
NPT 1"
PG 29
19
51,5
60
14
42
1.315.1000.70
1.315.1001.70
Colors grey (RAL 7035), black (RAL 9005)
Operating Temperature - 20 °C – 80 °C (- 4 °F – 176 °F)
Material Polyamide
Accessories
90° Snap Elbow
Metr., PG, NPT
Protection IP 68 (NEMA 6)
O-Ring Buna-N
AG IG GL H L
Number Number
mm mm mm mm
grey black
Dimensions and specifications may be changed without prior notice
