86
d d
RoHS
PG 7 / KR PG 9 1,5* 1.089.0712.19 1.089.0799.19
PG 9 / KE PG 7 / KR PG 11 M 16 x 1,5 NPT 3/8" 4 x 1,4 1.089.0900.19 2 x 3 1.089.0901.19 1.089.0999.19
5 x 1,6 1.089.0902.19 10 x 1,4 1.089.0904.19
4 x 2,3 1.089.0908.19 1 x 2,2* 1.089.0916.19
PG 11 / KE PG 9 / KR PG 13,5 M 16 x 1,5 / 16 2 x 3 1.089.1100.19 3 x 3 1.089.1101.19 1.089.1199.19
2 x 4 1.089.1102.19 3 x 1,5 1.089.1103.19
PG 13,5 / KE PG 11 / KR PG 16 M 20 x 1,5 NPT 1/2" 3 x 2 1.089.1300.19 6 x 3 1.089.1301.19 1.089.1399.19
3 x 4 1.089.1302.19 2 x 5 1.089.1303.19
3 x 3 1.089.1304.19 1 x 5* 1.089.1312.19
PG 16 / KE PG 13,5 / KR PG 21 M 16 x 1,5 / 16NPT 1/2" (16) 4 x 4 1.089.1602.19 5 x 4 1.089.1603.19 1.089.1699.19
6 x 4 1.089.1604.19 2 x 6 1.089.1605.19
6 x 3 1.089.1607.19 3 x 4 1.089.1601.19
4 x 5 1.089.1611.19 2 x 4,5 1.089.1614.19
PG 21 / KE PG 16 M 25 x 1,5 NPT 3/4" 4 x 6 1.089.2100.19 3 x 7 1.089.2101.19 1.089.2199.19
2 x 8 1.089.2102.19 4 x 5 1.089.2103.19
3 x 5,2 1.089.2106.19 1 x 5,8* 1.089.2113.19
PG 29 M 32 x 1,5 NPT 1"/1 1/4" 6 x 6,5 1.089.2900.19 4 x 9 1.089.2901.19 1.089.2999.19
2 x 6 1.089.2905.19
PG 36 M 40 x 1,5 NPT 1 1/2" 5 x 9 1.089.3600.19 7 x 9 1.089.3601.19 1.089.3699.19
6 x 8 1.089.3602.19 2 x 15 1.089.3603.19
PG 42 M 50 x 1,5 1.089.4299.19
PG 48 M 63 x 1,5 8 x 10 1.089.4800.19 6 x 12 1.089.4801.19 1.089.4899.19
Advice:
- Installation instruction see page 176
- Other materials available upon request
- The inserts are exclusively capable for the glands of the HSK series
Accessories
HSK-ME Metr., PG, NPT
Number of Number of
Fits the following sizes Holes Number Holes
Number Number
x d x d without holes
Material Elastomer
Operating Temperature - 40 °C – 100 °C (- 40 °F – 212 °F)
Dimensions and specifications may be changed without prior notice
* Slit version to accommodate terminated cable
Advice: The shown inserts are samples, more inserts upon request
Slit version
