05
32
D-Sub
9 09 66 118 750 . 09 66 118 650 .
15 09 66 218 750 . 09 66 218 650 .
25 09 66 318 750 . 09 66 318 650 .
37 09 66 418 750 . 09 66 418 650 .
9 09 66 128 770 . 09 66 128 670 .
15 09 66 228 770 . 09 66 228 670 .
25 09 66 328 770 . 09 66 328 670 .
37 09 66 428 770 . 09 66 428 670 .
9 09 66 108 0001 09 66 108 0001
15 09 66 208 0001 09 66 208 0001
25 09 66 308 0001 09 66 308 0001
37 09 66 408 0001 09 66 408 0001
D-Sub
DIN 41 652 · CECC 75 301-802
Performance levels
Explanations see page 05.04
þ
Other performance levels on request
Male connector 2)
pitch 1.27 mm
metal shell with dimples
Female connector 2)
pitch 1.27 mm
metal shell
Please insert digit for flange thread
Performance level
3
Performance level
2
No. of
Identification contacts Part No.
Strain relief clamp
plastic for male
and female connector
ø 3.1 mm hole þ 0
M3 þ 1) 1 1)
4-40 UNC þ 2
Insulation displacement termination
Number of contacts
9--37
1) Not normally kept in stock
2) Not released for halogen free flat cables
