CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Panel-mounted socket
Order No.
Product description
Type of contact
Number of contacts
Conductor size
Standard
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Mounting
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N6R AF N6R BFE
931 855-001
Panel-mounted socket with metal screw-in
casing
female
6 + PE
max. 1.5 mm 2
DIN 43651
grey, metallic
PG 13.5
120 °
ø 17
7.5
min.11
Nut size
22
18.2
29.7
38.2
max.7 PG 13.5
ø 29.5
M26x1.5
Nut size
27
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted socket, not assembled, in
polythene bag, with assembly instructions
can be plugged into N6R FM R,
N6R EM;
coding NC 6,
order no. 831 002-011;
protective cover SHK 2,
order no. 733 845-001
contacts: RBC 162
931 730-106
Panel-mounted socket with flange
female
6 + PE
max. 1.5 mm 2
DIN 43651
grey
M4
35 +0.2
45 ±0.3
4.5
M26x1.5
56
45
5
35
10
M3
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
flange
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted socket, not assembled, in
polythene bag, with assembly instructions
can be plugged into N6R FM R,
N6R DM;
coding NC 6,
order no. 831 002-011;
protective cover SHK 2,
order no. 733 845-001
contacts: RBC 162
