362
CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Surface mounted connector
Order No.
Product description
Type of contact
Number of contacts
Conductor size
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Mounting
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N11R BM FA S N11R BM FA F Metall/metal
933 699-001
Surface-mounted connector with flange
male
11 + PE
max. 0.5 mm 2
grey
5
Nut size
22 4.5
ø 19.4
M26x1.5
25
35.3
ø 3.4
23
30
r 3
1.6 mm
AC 25 V / DC 50 V
5 A
≤ 5 mOhm
solder, concave pins
0.14 mm 2 to 0.5 mm 2
flange
Ag
PET
Zn Al/Ni
IP 65
-40 °C to +90 °C
10 pieces
1 surface-mounted connector, not assembled,
in polythene bag with assembly instructions
can be plugged into N11R EF S;
protective cover SHK 2,
order no. 733 845-001
934 392-001
Surface-mounted connector with flange and fil-
ter selection 11 x 1nF,
metal housing
male
11 + PE
grey
4.5
ø 19.2
M26x1.5
ø 3.4
23
30
r 3
32
38.8
1.6 mm
AC 25 V / DC 50 V
5 A
≤ 5 mOhm
solder, solid pins
flange
Ag
PET
Zn Al/Ni
IP 65
-40 °C to +90 °C
50 pieces
can be plugged into N11R EF S;
protective cover SHK 2,
order no. 733 845-001
