CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Accessories NR-series
Order No.
Product description
Cable gland
Cable diameter
Housing Color
Drawing
Technical data
Rated voltage
Rated current
Contact resistance
Type of termination
Material
Housing material
O-Ring
Environmental conditions
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Accessories to order separately
Type N6R 3 LED 24 N6R 3 LED 24 DB
831 411-001
LED insert with 3 LEDs (green, red, yellow) to
indicate operation conditions
2
1
4
3
5
6
YE
RD
GN
(+)
(+)
(-)
DC 24 V
10 A
≤ 5 mOhm
plug in
-40 °C to +90 °C
10 pieces
can be plugged into N6R FF S 11
831 618-001
LED insert with 3 LEDs (green, yellow, red) to
indicate operation conditions
2
1
4
3
5
6
RD
YE
GN
(+)
(+)
(-)
DC 24 V
10 A
≤ 5 mOhm
plug in
-40 °C to +90 °C
10 pieces
can be plugged into N6R FF S 11
