CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Angled cable socket
Order No.
Product description
Type of contact
Number of contacts
Cable gland
Cable diameter
Conductor size
Standard
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N6R FF R N6R FF
931 553-106
Angled cable socket,
strain relief by means of a clamping cage and
knurled screw
female
6 + PE
PG 11
7 mm to 9 mm
max. 1.5 mm 2
DIN 43651
grey
25.5
53
14.8
PG 11
Nut size
19
10
max.29.5
40
max.11
M3
7.5
ø 12.5
Nut size
22
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 cable socket, with knurled screw, not assem-
bled, in polythene bag, with assembly instruc-
tions
can be plugged into N6R AM,
N6R AM..., N6R BM..., N6R DM;
coding NC 6,
order no. 831 002-011
contacts: RBC 162
931 435-106
Angled cable socket
strain relief by means of a clamping cage
female
6 + PE
PG 11
7 mm to 9 mm
max. 1.5 mm 2
DIN 43651
grey
25.5
53
14.8
PG 11
Nut size
19
10
max.29.5
40
max.11
M3
Nut size
22
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 cable socket, with central screw M 3 x 60, not
assembled, in polythene bag, with assembly
instructions
can be plugged into N6R AM,
N6R AM..., N6R BM..., N6R DM;
coding NC 6,
order no. 831 002-011
contacts: RBC 162
