Northern Connectors Hirschmann NR-Series Circular Connectors - Manual (Page 16)

359
N6R AM 5 N11R AM N11R AM 5
931 773-001
Panel-mounted connector with metal screw-in
insert in the casing (metal segment)
male
6 + PE
max. 1.5 mm 2
DIN 43651
grey
PG 13.5
120 °
ø 17
min.11
7.5
Nut size
22 8 17.6
26.5
7
PG 13.5
ø 29.5
M26x1.5
Nut size
27
max.10
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector, not assembled, in
polythene bag with assembly instructions
can be plugged into N6R FF,
N6R FF R, N6R EF;
coding NC 6,
order no. 831 002-011
protective cover SHK 2,
order no. 733 845-001
contacts: RSC 162
932 626-106
Panel-mounted connector with metal screw-in
casing
male
11 + PE
max. 0.5 mm 2
DIN 43651
grey
min.11
PG 13.5
120 °
ø 17
8
Nut size
22
8 17.6
26.5
PG 13.5
ø 29.5
M26x1.5
Nut size
27 35.3
1.6 mm
AC/DC 60 V
5 A
≤ 5 mOhm
crimp
0.14 mm 2 to 0.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector, not assembled, in
polythene bag with assembly instructions
can be plugged into N11R FF, N11R EF;
protective cover SHK 2,
order no. 733 845-001
contacts: RSC 162/1
932 627-106
Panel-mounted connector with metal screw-in
casing (metall segment)
male
11 + PE
max. 0.5 mm 2
DIN 43651
grey
Pg 13.5
120 °
ø 17
7.5 10.5
Nut size
22 8 17.6
26.5
7
PG 13.5
ø 29.5
M26x1.5
Nut size
27
max.10
1.6 mm
AC/DC 60 V
5 A
≤ 5 mOhm
crimp
0.14 mm 2 to 0.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector, not assembled, in
polythene bag with assembly instructions
can be plugged into N11R FF, N11R EF;
protective cover SHK 2,
order no. 733 845-001
contacts: RSC 162/1
