361
CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Surface mounted connector
Order No.
Product description
Type of contact
Number of contacts
Conductor size
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Mounting
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N6R BM FA N6R BM FA S
932 437-206
Surface-mounted connector with flange
male
6 + PE
max. 1.5 mm 2
grey
Nut size
22 4.5
ø 19.4
M26x1.5
25
35.3
ø 3.4
23
30
r 3
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm
2 to 1.5 mm 2
flange
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 surface-mounted connector with flat gasket,
not assembled, in polythene bag with assembly
instructions
can be plugged into N6R FF,
N6R FF R, N6R EF, N6R FF S 11;
coding NC 6,
order no. 831 002-011
protective cover SHK 2,
order no. 733 845-001,
contacts: RSC 162
933 710-001
Surface-mounted connector with flange
male
6 + PE
max. 1.5 mm 2
grey
5
Nut size
22 4.5
ø 19.4
M26x1.5
25
35.3
ø 3.4
23
30
r 3
1.6 mm
AC 25 V / DC 50 V
5 A
≤ 5 mOhm
solder, concave pins
0.5 mm
2 to 1.5 mm 2
flange
Ag
PET
Zn Al/Ni
IP 65
-40 °C to +90 °C
10 pieces
1 surface-mounted connector, not assembled,
in polythene bag with assembly instructions
can be plugged into N6R EF S;
coding NC 6,
order no. 831 002-011
protective cover SHK 2,
order no. 733 845-001
