Northern Connectors Hirschmann NR-Series Circular Connectors - Manual (Page 14)

357
N6R AM 2 D N6R AM 2 M20 N6R AM 2 D M20
932 207-206
Panel-mounted connector with contact bearer
in the casing (monoblock design), pins hermeti-
cally mounted to prevent ingress of liquids
male
6 + PE
max. 1.5 mm 2
DIN 43651
grey
PG 13.5
120 °
ø 17
8
min.11
35.3
PG 13.5
ø 29.5
M26x1.5
Nut size
27
8 17 23.5
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
solder, concave pins
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector with O-Ring in
polythene bag with assembly instructions
can be plugged into N6R FF,
N6R FF R, N6R EF;
coding NC 6,
order no. 831 002-011
protective cover SHK 1,
order no. 733 849-011
931 592-004
Panel-mounted connector with contact bearer
in the casing (monoblock design)
male
6 + PE
max. 1.5 mm 2
DIN 43651
grey
min.11
M20x1.5
120 °
ø 17
8
35.3
M20x1.5
ø 29.5
M26x1.5
Nut size
27
8 17 23.5
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
M20x1.5
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector with O-Ring in
polythene bag with assembly instructions
can be plugged into N6R FF,
N6R FF R, N6R EF;
coding NC 6,
order no. 831 002-011
protective cover SHK 1,
order no. 733 849-011
contacts: RSC 162
932 207-406
Panel-mounted connector with contact bearer
in the casing (monoblock design), pins hermeti-
cally mounted to prevent ingress of liquids
male
6 + PE
max. 1.5 mm 2
DIN 43651
grey
M20x1.5
120 °
ø 17
8
min.11
35.3
M20x1.5
ø 29.5
M26x1.5
Nut size
27
8 17 23.5
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
solder, concave pins
0.5 mm 2 to 1.5 mm 2
M20x1.5
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector with O-Ring in
polythene bag with assembly instructions
can be plugged into N6R FF,
N6R FF R, N6R EF;
coding NC 6,
order no. 831 002-011
protective cover SHK 1,
order no. 733 849-011
