CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Panel-mounted connector
Order No.
Product description
Type of contact
Number of contacts
Conductor size
Standard
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Mounting
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N11R AM 2 M20 N11R AM 2 D M20
934 337-106
Panel-mounted connector with metal screw-in
casing (monoblock design)
male
11 + PE
max. 0.5 mm 2
DIN 43651
grey
M20x1.5
120 °
ø 17
8
min.11
25.3
M20x1.5
ø 29.5
M26x1.5
Nut size
27
8 17
35.3
1.6 mm
AC/DC 60 V
5 A
≤ 5 mOhm
crimp
0.14 mm 2 to 0.5 mm 2
M20x1.5
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector with O-Ring in
polythene bag with assembly instructions
can be plugged into N11R FF, N11R EF;
protective cover SHK 2,
order no. 733 845-001
contacts: RSC 162/1
934 338-106
Panel-mounted connector with metal screw-in
casing (monoblock design),
Stifte flüssigkeitsdicht montiert
male
11 + PE
max. 0.5 mm 2
DIN 43651
grey
M20x1.5
120 °
ø 17
8
min.11
25.3
M20x1.5
ø 29.5
M26x1.5
Nut size
27
8 17
35.3
1.6 mm
AC/DC 60 V
5 A
≤ 5 mOhm
solder, concave pins
0.14 mm 2 to 0.5 mm 2
M20x1.5
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 panel-mounted connector with O-Ring in
polythene bag with assembly instructions
can be plugged into N11R FF, N11R EF;
protective cover SHK 2,
order no. 733 845-001
