354
CIRCULAR CONNECTORS NR-SERIES
Circular connectors NR-series > Cable plug
Order No.
Product description
Type of contact
Number of contacts
Cable gland
Cable diameter
Conductor size
Standard
Housing Color
Drawing
Technical data
Pin dimensions
Rated voltage
Rated current
Contact resistance
Type of termination
Suitable cables
Material
Contact surface material
Contact bearer material
Housing material
Environmental conditions
Protection class (IEC 60529)
Temperature range
Packing unit
Packaging unit
Scope of delivery and accessories
Scope of delivery
Accessories to order separately
Type N6R DM N6R FM R
932 273-106
Cable coupling ,
strain relief by means of a clamping cage
male
6 + PE
PG 11
7 mm to 9 mm
max. 1.5 mm 2
DIN 43651
grey
≈
76
PG 11
Nut size
22
9
≈ 17.5
M26x1.5
Nut size
19
Nut size
27
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 coupling connector, not assembled, in poly-
thene, with assembly instructions
can be plugged into N6R EF;
protective cover SHK 2,
order no. 733 845-0014
contacts: RSC 162
931 727-106
Angled cable plug with knurled screw,
strain relief by means of a clamping cage
male
6 + PE
PG 11
7 mm to 9 mm
max. 1.5 mm 2
DIN 43651
grey
25.5
53
15.2
PG 11
Nut size
19
10
max.29.5
40
max.11
M3
7.5
Nut size
22
1.6 mm
AC/DC 250 V
10 A
≤ 5 mOhm
crimp
0.5 mm 2 to 1.5 mm 2
Ag
PET
PET
IP 65
-40 °C to +90 °C
10 pieces
1 cable plug, with knurled screw, not assemb-
led, in polythene, with assembly instructions
can be plugged into N6R AF,
N6R BFE, N6R DM;
coding NC 6,
order no. 831 002-011
contacts: RSC 162
