Model NE-4000 Multi-Phaser™
Publication #1200-01 47 09/05/14
11.5 Specifications
11.5.1 Mechanical & Electrical
Syringe sizes: Up to 60 mL. 140 mL partially filled
Number of syringes: 2
Motor type: Step motor
Motor steps per revolution: 200
Microstepping: 1/8 to 1/2 depending on motor speed
Advance per step: 0.41852679 µm to 1.67410714 µm depending on motor speed
Motor to drive screw ratio: 15/28
Drive screw pitch: 20.32 revolutions/”
Power connector: 2.1 mm, center positive, DC
Voltage at DC connector: 12V DC at full load
Amperage: 1000 mA at full load
Power supply type: Unregulated linear external wall adapter, country and power source
specific (or compatible regulated power supply)
Power supply output rating: 12V DC @ 1000 mA
Dimensions: 8 3/4” x 5 3/4” x 4 1/2” (LxWxH)
(22.86 cm x 14.605 cm x 11.43 cm)
Weight: 3.6 lbs. (1.63 kg)
11.5.2 Operational
Maximum speed: 18.08035714 cm/min
Minimum speed: 0.008276531 cm/hr
Maximum pumping rate: 6023 mL/hr with a B-D 60 mL syringe
Minimum pumping rate: 1.436 µL/hr with a B-D 1 mL syringe
Maximum force: 100 lbs. at minimum speed, 18 lbs. at maximum speed
Number of Program Phases: 41
RS-232 pump network: 100 pumps maximum
RS-232 selectable baud rates: 300, 1200, 2400, 9600, 19200
Syringe inside diameter range: 0.100 to 50.00 mm
11.6 Custom Applications
For specialized and OEM applications, contact your dealer or New
Era Pump Systems Inc. Custom modifications can be made to the
mechanics or the firmware.
