Model NE-4000 Multi-Phaser™
Publication #1200-01
37
09/05/14
VOLUME DISPENSED
DIS
Queries volume dispensed only. Set not applicable.
Response:
I
Where: “I
volume.
CLEAR VOLUME DISPENSED
CLD { INF | WDR }
Sets the Infused or withdrawn volume dispensed to 0. Command is only valid while the Pumping
Program is not operating. Query is not applicable.
INF
= Infusion volume
WDR
= Withdrawn volume
Query is not applicable.
9.4.3
Configuration and Setup Commands
New settings for any of the following commands will be stored in the non-volatile memory.
LOW MOTOR NOISE
LN [
Set/query low motor noise mode. Increases motor stepping resolution.
ALARM SETUP
AL [
Set/query alarm setup mode. Set alarm enables or disables alarm buzzer mode.
POWER FAIL SETUP
PF [
Set/query Power Failure mode. Set Power Failure enables or disables Power Failure mode.
TTL I/O OPERATIONAL TRIGGER DEFAULT SETUP
TRG [
Set/Query TTL I/O Operational Trigger (Pin 2) default input configuration.
TTL I/O Operational Trigger is set to
FT
= Foot switch trigger (falling edge start/stop)
FH
= Foot switch hold (falling edge start, rising edge start)
F2
= Foot switch reverse (rising edge start/stop)
LE
= Level trigger (rising edge start, falling edge stop)
ST
= Start only trigger (falling edge start)
T2
= Start only trigger reversed (rising edge start)
SP
= Stop only trigger (falling edge stop)
P2
= Stop only trigger reversed (rising edge stop)
RL
= Start on low level
RH
= Start on high level
SL
= Stop on low level
SH
= Stop on high level
OF
= Trigger off (disabled)
