Model NE-4000 Multi-Phaser™
Publication #1200-01 36 09/05/14
Set/query volume to be dispensed:
Applicable only with “Rate Data Functions”. Can only be set when the Pumping Program is not
operating. The volume units are set according to the current syringe diameter setting. Do not send the
volume units when setting the volume.
Example: VOL 12.45
Sets the current phase “Volume to be Dispensed” to 12.45.
Set volume units:
Overrides the default volume units set when the syringe diameter is set.
Example: VOL UL
Sets all volume units to µl.
Query response:
PUMPING DIRECTION
DIR [ INF | WDR | REV | STK ]
Set/query pumping direction
INF
= Infuse
WDR = Withdraw
REV = Reverse pumping direction
STK = “Sticky Direction” (See “Sticky Direction”, sec: .5.8.1)
Applicable with all Program Phase functions. Cannot be set when the Pumping Program is operating and
the “Volume to be Dispensed” is non-zero.
The pumping direction cannot be changed if an alarm condition exists.
Query response: { INF | WDR | STK}
When set to “Sticky Direction”, query will respond with the current pumping direction ( INF or WDR)
while pumping.
9.4.2 Pump Operational Commands
START PUMPING PROGRAM
RUN [ ]
[E [ ] ]
Starts the Pumping Program operation.
If the Pumping Program was paused, then the Pumping Program resumes at the point where it was
stopped. Otherwise, the Pumping Program starts from Phase 1.
Sub-Programs: If a Phase number is specified (), then the Pumping Program will start at the
specified Phase number. By programming sub-programs in different sections of the Pumping Program
memory, this command can be used to individually execute different sub-programs.
The pump cannot be started if an alarm condition exists.
E [ ]
Trigger a Pumping Program Event while the Pumping Program is active.
Triggers a pre-defined event defined with the Pumping Program’s Event function, causing an immediate
jump to the Pumping Program Phase defined by the event function.
If is specified, the program will immediately jump to the Pumping Program Phase specified
by , and cancel any other event set by the Pumping Program.
PURGE PUMP
PUR
Starts purge. Pump infuses or withdraws at the top speed, depending on the pumping direction.
STP command or ‘Start/Stop’ key will stop the pump.
STOP PUMPING PROGRAM
STP
If the Pumping Program is operating, the pump will be stopped and the Pumping Program will be paused.
If the Pumping Program is paused, the stop command will cancel the pause and reset the Pumping
Program to Phase 1.
